R4245 Screwdriver bit socket 1/4″ for recessed TX screws, short

Order Code: 5694

Specification

About this product

  • With pressed-in, phosphated pin
  • Hand-operated, knurled grip
  • Drive end brightly polished
  • Square drive as per DIN 3120 - C 6.3, ISO 1174, with ball retention groove
  • Chrome-vanadium steel

Information

  • Contents (Qty of pieces): 1 tlg.
  • Total length [mm]: 37 mm
  • Drive connector square fem: 6,3 mm
  • Total width [mm]: 12 mm
  • Material: Chrome-vanadium steel
  • Drive connector square fem: 1/4"
  • Working length: 37,0 mm
  • Insert-Ø 1: 12,0 mm
  • Tip length: 15,0 mm
  • Surface: Drive end brightly polished
  • Standard: DIN 3120 – C 6,3 ISO 1174
  • REACH registration available: 0
  • Insert Ø Actuator: 12 mm
  • :
  • :
  • :
  • :
  • :
  • :
  • :
  • :
  • :
  • :
  • :
  • :
  • :
  • :
  • :
  • :
  • :
  • :
  • :
  • :
  • :
  • :
  • :
  • :
  • :
  • :
  • :
